| Camera |
| Image Device |
1/2.7" 2mega-pixel CMOS sensor |
| Effective Pixels |
1920 x 1080@30fps |
| Sensitivity |
Color: 0.05 lux (AGC ON)
B / W: 0.01 lux (AGC ON)
|
| Lens |
3 ~ 10.5mm vari-focal lens with auto iris and IR-cut filter/ F1.4 |
| View Angle |
H: 34.89~106.72 degrees
V: 19.38~61.26 degrees
|
| Video |
| Video Encoder |
H.264 and Motion JPEG simultaneously |
| Video Profile |
- H.264 1080p / 720p / VGA / QVGA / QCIF
- JPEG 1080p / 720p / VGA / QVGA / QCIF
- 3GPP VGA / QVGA / QCIF
|
| Frame Rate |
HD-1080p / 720p / VGA / QVGA / QCIF up to 30fps |
| Image Setting |
Brightness, Contrast, Hue, Saturation, Sharpness,
AGC, Shutter Time, Sense-Up, WDR, Anti Fog, Lens Distortion Correction, Flip, Mirror, Noise Reduction, White Balance, Day & Night adjustable
|
| Streaming |
Simultaneous multi-profile streaming
M-JPEG streaming over HTTP
Supports 3GPP mobile surveillance
Controllable frame rate and bandwidth
Constant and variable bit rate (H.264)
|
| Audio |
| Audio Encoder |
RTSP: G.711 / G.726 |
| Audio Streaming |
Two-way |
| Microphone |
Phone jack |
| Audio Output |
Phone jack |
| Network and Configuration |
| Network Standard |
IEEE 802.3 / IEEE 802.3u |
| Supported Protocols |
IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, PLANET DDNS/ PLANET Easy DDNS, 802.1X, SNMP, DHCP, UPnP, RTSP, RTP, RTCP, PPPoE, 3GPP, ICMP |
| Security |
Password protection, user access log, https |
| Users |
10 simultaneous unicast users |
| Ethernet |
10/100Mbps auto negotiation |
| Antenna |
5dBi Dipole Antenna |
| Antenna Connector |
RP-SMA Female |
| Frequency |
2.4GHz |
| Wireless Channels |
America / FCC: 2.414~2.462GHz (11 Channels)
Europe / ETSI: 2.412~2.472GHz (13 Channels)
Japan / TELEC: 2.412~2.484GHz (14 Channels)
|
| RF Transmit Power |
OFDM: 15 dBm
CCK: 17 dBm
|
| Output Power |
802.11b: 17dBm (default) +/- 1dBm
802.11g: 14dBm (default) +/- 1dBm
802.11n: 14dBm (default) +/- 1dBm
|
| Receiver Sensitivity |
802.11b→1Mbps: -83dBm 11Mbps: -76dBm
802.11g→6Mbps: -82dBm 54Mbps: -65dBm
802.11n (BW20)→MCS0: -82dBm MCS7: -65dBm
802.11n (BW40)→MCS0: -79dBm MCS7: -61dBm
|
| Data Rate |
802.11b Standard Data Rates: 1, 2, 5.5 and 11Mbps
802.11g Standard Data Rates: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n Standard Data Rates: Legacy and High Throughput Modes, supporting 20 / 40MHz Bandwidth MCS0~7 (150Mbps PHY Rate)
|
| Wireless Security |
WEP, WPA-PSK and WPA2-PSK encryptions |
| System Integration |
| Application Programming Interface |
Open API for software integration
SDK
ONVIF compliant
|
| Alarm Triggering |
Intelligent video motion detection and external input |
| Motion Detection |
3-zone video motion detection |
| Alarm Events |
File upload via FTP, email and SAMBA.
External output activation
Configurable pre/post alarm buffering
|
| Video Buffer |
Pre-5sec and post-10sec alarm buffering |
| General |
| Power Supply |
12V DC external power adapter |
| Power Consumption |
12V DC: 4W (IR Off); 8W (IR On) |
| Illumination LED |
IR LEDs |
| IR LED |
Infrared LED × 35pcs |
| IR Wavelength |
850nm |
| IR Distance |
25m |
| Protection Class |
IP-66 classification |
| Operating Temperature |
-10 ~ 50 degrees C |
| Operating Humidity |
20 ~ 80% (non-condensing) |
| Dimensions (Φ x L) |
83 x 180 mm |
| Weight |
1350g |
| Viewing System |
| OS |
Windows® XP, Vista 32bit, Win7 32bit, Server 2003 |
| Browser |
IE 8.0 or latter |
| Cell Phone |
With 3GPP player |
| Video Player |
VLC, Quick Time, Real Player |
| Software |
| Monitor/ Recording / Management |
PLANET CV3P (2-ch Cam Viewer Three Pro Trail Version)
PLANET CV3L (64-ch Cam Viewer Three Lite Bundled Version)
|
| Search & Installation |
PLANET Smart Discovery Lite |
