| Interfață |
| Cupru |
1-Port Fast Ethernet TP interface, Auto-negotiation, Auto-MDI / MDI-X with PoE injector function |
| Fibră |
Multi-mode: 50/125µm or 62.5/125µm optic fiber
Single-mode: 8.3/125, 8.7/125, 9/125µm optic fiber
|
| Tip port fibră (conector) |
FTP-802 : SC
FTP-802S15 : SC |
| Distanța de cablu |
FTP-802 : 2km
FTP-802S15 : 15km
|
| Frecventa optica |
FTP-802 : 1310nm
FTP-802S15 : 1310nm
|
| Lansarea puterii (dBm) |
FTP-802 : Max.-14 Min.-19.0
FTP-802S15 : Max. -7 Min.-20
|
| Primiți sensibilitate |
FTP-802 : -34.5
FTP-802S15 : -28
|
| Putere maximă de intrare |
FTP-802 : -14
FTP-802S15 : -8
|
| Putere peste Ethernet |
| PoE Standard |
IEEE 802.3af Power over Ethernet |
| Puterea de ieșire |
PoE 48V DC, Max. 15.4watts, 350mA |
| Alocarea pinilor de putere |
1/2(+) , 3/6(-) |
| Specificații hardware |
| Schimbarea arhitecturii |
Store-and-Forward |
| Controlul debitului |
Back pressure for Half Duplex mode
IEEE 802.3x Pause Frame for Full Duplex mode |
| LED |
System: Power, Status
FX / LNK: Data Active, Fiber Link
TX / LNK: 10/100 Link / Active
PoE in Use: Detect PSE Device
|
| Dimensiuni (H x W x D) |
26 x 70 x 97 mm |
| Greutate |
0.2 kg |
| Alimentare electrică |
48V DC, 0.4A External AC-to-DC adapter |
| Temperatura |
0~50 degree C |
| Umiditatea funcționează |
5~90% (non-condensing) |
| Modul LFP |
Enable: when either TP port or FX port is broken, shut down the other port
Disable: Link LED indicators is still on if connection of the other end is broken
|
| Conformitatea standardelor |
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Protocoale și conformitatea standardelor |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
|
| cabluri |
TP: Cat 5/5e UTP cable
Fiber: Multi-mode: 50/125µm or 62.5/125µm optic fiber
Single-mode: 8.3/125, 8.7/125, 9/125µm optic fiber
|
