| Specificații hardware |
| Porturi 10/100 / 1000Base-T |
8 |
| Dimensiune (L x Î x H) |
135 x 87 x 32 mm |
| Greutate |
473g |
| Necesitatea de alimentare |
12~48 VDC, Redundant power with polarity reverse protection function |
| Consum de energie / dizolvare |
13.2 Watts / 45BTU |
| Instalare |
DIN rail kit and wall mount ear |
| Alarma |
Provides one relay output for power fail
Alarm Relay current carry ability: 1A @ DC 24V
|
| Comutare specificație |
| Schema de procesare a comutatorului |
Store-and-Forward |
| Tabel de adrese |
8K entries |
| Tampon |
176 kilobytes |
| Controlul debitului |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
| Comutați țesătura |
16Gbps |
| Capacitatea de transfer (pachet pe secundă) |
11.9Mpps |
| Jumbo Frame |
9K |
| Cabluri de rețea |
10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters, max.)
EIA/TIA-568 100-ohm STP (100meters, max.)
|
| Conformitatea standardelor |
| Respectarea standardelor |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-duplex flow control
|
| Temperatura |
Operating: -40~75 Degree C
Storage: -40~75 Degree C
|
| Umiditate |
Operating: 5~90%, Storage: 5~90% (Non-condensing) |
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Siguranță |
UL, cUL |
| Încercarea de stabilitate |
IEC60068-2-32(Free fall), IEC60068-2-27(Shock), IEC60068-2-6(Vibration) |
