| Specificații hardware |
| Porturi 10 / 100Base-TX |
5 |
| Dimensiune (L x Î x H) |
135 x 87 x 32 mm |
| Greutate |
438g |
| Necesitatea de alimentare |
12~48 VDC, Redundant power with polarity reverse protection function |
| Consum de energie / dizolvare |
3.9 Watts / 13BTU |
| Instalare |
DIN rail kit and wall mount ear |
| Alarma |
rovides one relay output for power fail
Alarm Relay current carry ability: 3A @ DC 30V |
| Comutare specificație |
| Schema de procesare a comutatorului |
Store-and-Forward |
| Tabel de adrese |
2K entries |
| Controlul debitului |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
| Comutați țesătura |
1Gbps |
| Capacitatea de transfer (pachet pe secundă) |
0.74Mpps |
| Cabluri de rețea |
10/100Base-TX:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters, max.)
EIA / TIA-568 100-ohm STP (100meters, max.) |
| Conformitatea standardelor |
| Respectarea standardelor |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-duplex flow control
|
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Încercarea de stabilitate |
IEC60068-2-32(Free fall),IEC60068-2-27(Shock),IEC60068-2-6(Vibration) |
| Specificație de mediu |
| Temperatura |
Operating: -40~75 Degree C
Storage: -40~75 Degree C
|
| Umiditate |
Operating: 5~90%
Storage: 5~90% (Non-condensing) |
