| Specificații hardware |
| Cupru |
Ports
4 x 10/100Base-TX, Auto-negotiation, Auto-MDI / MDI-X
Cable
10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters, max.)
100Base-TX : 2-pair UTP Cat. 5 cable (100meters, max.) |
| Optic |
Port
1 x 100Base-FX
Cable
ISW-511T: 50/125μm / 62.5/125μm fiber
ISW-511TS15: 9/125μm fiber
Mode
ISW-511T: Multi-mode
ISW-511TS15: Single-mode
Distance
ISW-511T: 2km
ISW-511TS15: 15km
Frequency
ISW-511T: 1310nm
ISW-511TS15: 1310nm
Launch Power
ISW-511T: Max. -14dBm, Min. -20dBm
ISW-511TS15: Max. 0dBm, Min. -20dBm
Receive Sensitivity
ISW-511T: -32dBm
ISW-511TS15: -32dBm
Max. Input Power
ISW-511T: -14dBm
ISW-511TS15: 0dBm |
| Dimensiune (L x Î x H) |
135 x 97 x 32 mm |
| Greutate |
436g |
| Necesitatea de alimentare |
12~48V DC
Redundant power with polarity reverse protection function
|
| Consum de energie / dizolvare |
13.7 Watts / 46 BTU |
| Instalare |
DIN Rail Kit and Wall Mount Ear |
| Alarma |
Provides one relay output for power fail
Alarm Relay current carry ability: 1A @ DC 24V
|
| Comutare specificație |
| Schema de procesare a comutatorului |
Store-and-Forward |
| Tabel de adrese |
2K entries |
| Tampon |
1Mbit |
| Controlul debitului |
Back pressure for half duplex,
IEEE 802.3x Pause Frame for full duplex
|
| Comutatorul Fabric |
1Gbps |
| Capacitatea de transfer (pachet pe secundă) |
0.74Mpps @ 64Bytes
|
| Conformitatea standardelor |
| Respectarea standardelor |
IEEE 802.3 Ethernet, 10Base-T
IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX
IEEE 802.3x Full-duplex flow control
|
| Temperatura |
Operating: -40~75 Degree C
Storage: -40~85 Degree C
|
| Umiditatea funcționează |
Operating: 5~90%
Storage: 5~90% (Non-condensing) |
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Testul de stabilitate |
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
