| Specificații hardware |
| Versiunea hardware |
3 |
| Porturile de cupru |
5 x 10/100/1000Base-T RJ45 TP
auto-MDI/MDI-X, auto-negotiation
|
| Conector |
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
|
| Alarma |
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V
|
| LED |
3 x LED for system and power:
■ Green: DC Power 1
■ Green: DC Power 2
■ Green: Power Fault
2 x LED for each copper port
■ Green: 1000Mbps LNK/ACT
■ Orange:10/100Mbps LNK/ACT
|
| Protecția ESD |
6KV |
| Protecția EFT |
6KV |
| Cerinte de putere |
12~48V DC, Redundant power with polarity reverse protection function, 24V AC power support |
| Consum de energie / dizolvare |
4.8 watts / 16BTU (48V DC)
8.3 watts / 28BTU (24V DC)
|
| Instalare |
DIN rail kit and wall-mount ear |
| împrejmuire |
IP30 metal case |
| Dimensiuni (L x Î x H) |
135 x 87 x 32 mm |
| Greutate |
498g |
| Comutare Specificații |
| Schema de procesare a comutatorului |
Store-and-Forward |
| Tabel de adrese |
2K entries |
| Memorie tampon |
1M bits on-chip buffer memory |
| Controlul debitului |
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
|
| Comutatorul Fabric |
10Gbps |
| Capacitatea de transfer (pachet pe secundă) |
7.4Mpps @64bytes |
| Jumbo Frame |
9K |
| Cabluri de rețea |
10/100/1000Base-T
Cat. 3, 4, 5, 5e, 6 UTP cable [100 meters (max.)]
EIA/TIA-568 100-ohm STP [100 meters (max.)]
|
| Conformitatea standardelor |
| Respectarea standardelor |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x full-duplex flow control
|
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Testul de stabilitate |
IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration)
|
| Mediu inconjurator |
| Temperatura |
Operating: -40~75 degrees C
Storage: -40~75 degrees C
|
| Umiditate |
Operating: 5~90%
Storage: 5~90% (non-condensing) |
