| Specificații hardware |
| Interfață |
Ethernet
1 x 10/100/1000BASE-T RJ45, Ethernet data output port
PoE in
1 x 10/100/1000BASE-T RJ45, PoE power input port |
| Comutator DIP |
12V/19V/24V DC output |
| Sursă de alimentare |
DC receptacle 2.5mm |
| Indicator cu LED |
System: Power x 1 (Green)
PoE-in-use x 2 (Green)
|
| Rata de date |
10/100/1000Mbps |
| Dimensiuni (L x Î x H) |
94 x 70.3 x 26.2 mm |
| Greutate |
300g |
| Instalare |
Desktop/wall mountable |
| împrejmuire |
Metal case |
| Cerinte de putere |
50~56V DC PoE |
| Curentul de ieșire al unității (la intrare de 56 Vcc) |
75-watt PoE input
- 5A@12V DC
- 3.15A@19V DC
- 2.5A@24V DC
|
| Consumul de energie |
Ethernet full loading without DC output:
3.7 watts
Full loading with maximum 12V DC, 5A output:
75 watts
|
| Cablu de rețea |
Ultra PoE (60W+)
4-pair UTP Cat. 5, 5e, 6, up to 100m (328ft)
802.3af/at PoE (15W/30W)
2-pair UTP Cat. 3, 4, 5, up to 100m (328ft)
|
| Putere peste Ethernet |
| PoE Standard |
802.3bt Type 3/Type 4 Power over Ethernet
4-pair 802.3at PoE+ and Cisco UPOE compliant with voltage within 50V-56V DC
|
| Puterea de ieșire |
DC 12V/19V/24V by DIP switch control |
| Tip de alimentare PoE |
End-span + Mid-span
End-span
Mid-span
|
| Conformitatea standardelor |
| Respectarea standardelor |
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3af Power over Ethernet
|
| Respectarea reglementărilor |
FCC, CE |
| Mediu inconjurator |
| Temperatura de Operare |
0 ~ 50 degrees C |
| Temperatura de depozitare |
-10 ~ 70 degrees C |
| Umiditatea de funcționare |
5 ~ 90%, non-condensing |
| Depozitare Umiditate |
5 ~ 90%, non-condensing |
| Accesorii standard |
| Conținutul pachetului |
One 15cm UTP straight network cable
Two external female plug cables:
- 5.5/2.5mm to 5.5/2.5mm
- 5.5/2.5mm to 5.5/2.1mm
|
