| Specificații hardware |
| porturi |
10/100Base-TX: 1 RJ-45, Auto-negotiation and Auto-MDI / MDI-X
VDSL: 1 RJ-11, female Phone Jack
PHONE: 1 RJ-11, Built-in splitters for POTS connection
|
| Comutator DIP |
4 position DIP switch |
| Funcționalitate |
• CO / CPE mode select
• Selectable fast and interleaved mode
• Selectable target band plan
• Selectable target SNR mode
|
| Codare |
• VDSL-DMT
- ITU-T G.993.1 VDSL
- ITU-T G.997.1
- ITU-T G.993.2 VDSL2 (Profile 17a Support)
|
| Indicatoare LED |
• One Power
• 3 for RJ-11 / VDSL2 WAN :
- Green, LNK / ACT
- Green, CO mode
- Green, CPE mode
• 2 for per RJ-45 10/100Base-TX port
- Green, LNK / ACT
- Green, Speed
|
| Cablare tip |
• 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
• 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
• VDSL: twisted-pair telephone wires (AWG24 or better) up to 1.6km
|
| Performanţă |
Full VDSL2 bandwidth up to: (Down Stream / Up Stream)
• Asymmetric Mode
- 200m -> 100/55Mbps
- 400m -> 90/50Mbps
- 600m -> 70/40Mbps
- 800m -> 60/25Mbps
- 1000m -> 45/15Mbps
- 1200m -> 35/10Mbps
- 1400m -> 30/6Mbps
- 1600m -> 25/4Mbps
• Symmetric Mode
- 200m -> 90/90Mbps
- 400m -> 90/90Mbps
- 600m -> 70/70Mbps
- 800m -> 55/50Mbps
- 1000m -> 40/35Mbps
- 1200m -> 30/25Mbps
- 1400m -> 25/20Mbps
- 1600m -> 20/15Mbps
|
| Dimensiune (L x Î x H) |
97 x 69 x 26 mm |
| Greutate |
0.4 kg |
| Necesitatea de alimentare |
5V DC 2A |
| Temperatura de Operare |
0~50 Degree C |
| Temperatura de depozitare |
-25~70 Degree C |
| Umiditatea de funcționare |
10~90%, relative humidity, non-condensing |
| Depozitare Umiditate |
10~90%, relative humidity, non-condensing |
| Conformitate standard |
| Reglementarea conformității |
FCC Part 15 Class A, CE |
| Respectarea standardelor |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
ITU-T
- G.993.1 (VDSL)
- G.997.1
- G.993.2 VDSL2 (Profile 17a )
|
| * Rata reală a datelor variază în funcție de calitatea cablului de cupru sau a cablului coaxial și a |
