| Hardware |
| LAN |
4 RJ-45 (10/100Base-TX, Auto-Negotiation) |
| WAN |
1 RJ-45 (10/100Base-TX, Auto-Negotiation) |
| Telephony Port |
4 RJ-45 (Euro-ISDN ST-interface)
|
| Standards and protocol |
| Call Control |
SIP 2.0 (RFC3261) |
| Registration |
Max. 30 nodes / SIP IP phones |
| Calls |
Max. 10 concurrent calls |
| Voice CODEC Support |
G.711, G.726, GSM, G.723.1 (5.3, 6.3kbps), G.729A (8kbps)
|
| Voice Processing |
Voice Active Detection,
DTMF detection/generation,
G.165/G.168 echo cancellation (ECN) (25 ms.),
Comfort noise generation (CNG),
Gain Control |
| PBX Features |
Support call hold, call waiting, 3-way call conference with feature phones (VIP-154T series, VIP-155PT and ATA series)
Built-in in-line call transfer
Unconditional, unavailable, busy call forward
Per-calling-number forward and rejection
Group-based call pick-up
Call-parking
Inter-PBX SIP trunking
Multi-room meet-me conference
Auto-attendant
Voice mail system
Call privilege grouping
ISDN interface for PSTN Inbound/outbound
ISDN disconnection tone detection
ISDN hunt group
Caller ID detection
Echo cancellation
In-band / RFC2833 / SIP-INFO DTMF translation
Music on hold
Direct line Outbound
900 / 0204 blocking
|
| Auto Attendant Features |
Configurable IVR prompts
Work time IVR
3-layer Auto Attendant
Key to reach operator
Timeout interval and timeout action
Music on ringing extensions
Forward to voice mail on no-answer |
| Voicemail Features |
User PIN
Multilingual
Multi-folder archive
Fast-forward, Rewind, Undelete
MWI notification
E-mail notification and attachment (Unified messaging)
Personal reception on unavailability and busy
Voicemail forwarding
Voicemail to email
Reply calls or new calls in voicemail menu
|
| Internet Sharing |
| Protocol |
TCP/IP, NAT, DHCP, HTTPs, DNS
|
| Advanced Function |
QoS
|
| Management |
HTTP |
| Environment |
| Operating |
Temperature 0~50 Degree C, 10~90% humidity
|
| Power Requirement |
12V DC
|
| EMC/EMI |
CE, FCC |
| Network and Configuration |
| Connection type |
Static IP, PPPoE, DHCP
|
| Management |
HTTPs (LAN / WAN access), HTTP (LAN access) |
