| Hardware Specification |
| Interface |
"Data" Input Ports: 12x RJ-45 STP
"PoE (Data+Power)" Output Ports: 12x RJ-45 STP
Management Port: 1 x RJ-45; 10/100Base-TX, auto-negotiation, auto-MDI / MDIX |
| Data Rate |
10/100/1000Mbps |
| LED |
System: Power x 1 (Green)
FAN Alert x 1(Green)
Management Port x 2: 10/100 (Orange / Green)
Per PoE Port: PoE in Use x 1 (Green) |
| Network Cable |
10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
1000Base-T: 2-pair UTP Cat. 5e, 6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m) |
| Dimension (W x D x H) |
440 x 200 x 44 mm (1U height) |
| Weight |
2.73kg |
| Power Requirement |
100-240V AC, 50/60 Hz |
| Power Consumption |
200 Watts max. |
| Cooling |
Fan x 1 |
| Power over Ethernet |
| PoE Standard |
IEEE 802.3af Power over Ethernet / Mid-Span PSE |
| PoE Power supply Type |
Mid-Span |
| PoE Power Output |
Per Port DC 48V 15.4 Watts |
| Power Pin Assignment |
4/5(+), 7/8(-) |
| PoE Power Budget |
190 Watts |
| Management |
| Management Interface |
Web, PLANET Smart Discovery Utility |
| PoE Management |
Power Limit by Priority and Total Limit
Per port power Enable / Disable
Power feeding priority
Current usage and status
Total power consumption
Per port power Schedule
|
| Management Feature |
System / Management functions setup
Web firmware upgrade
SNMP Trap for alarm notification of events
|
| Standards Conformance |
| Standards Compliance |
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3af Power over Ethernet
|
| Regulation Compliance |
FCC Part 15 Class A, CE |
| Environmental Specification |
| Operating |
Temperature: 0 ~ 50 Degree C
Relative Humidity: 5 ~ 95% (non-condensing)
|
| Storage |
Temperature: -40 ~ 70 Degree C
Relative Humidity: 5 ~ 95% (non-condensing)
|
