| Hardware Specification |
| Hardware Version |
Version 5 |
| 10/100/1000Base-T MDI/MDIX Ports |
16 |
| Throughput (packet per second) |
23.8Mpps |
| Switch Fabric |
32Gbps / non-blocking |
| Weight |
1.9kg |
| Power Consumption / Dissipation |
13 Watts / 44 BTU |
| Power Requirement |
100-240V AC, 0.6A, 50/60Hz |
| Dimension (W x D x H) |
440 x 180 x 45 mm, 1U height |
| Switch Processing Scheme |
Store-and-Forward |
| Address Table |
8K entries |
| Jumbo packet size |
9K |
| Flow Control |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
| Standards Conformance |
| Regulation Compliance |
FCC Part 15 Class A, CE |
| Standards Compliance |
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab(Gigabit Ethernet)
IEEE 802.3x (Full-duplex flow control)
|
| Environmental Specification |
| Temperature |
| Operating: | 0 ~ 50 Degree C | | Storage: | -10 ~ 70 Degree C |
|
| Humidity |
| Operating: | 5 ~ 95 Degree C | | Storage: | 5 ~ 95 Degree C |
|
